Carrier Set Ducasse DN150 CF for Wood Doors – 1 Door up to 330 lbs (150 kg)

The DN150 CF Carrier Set is designed for top sliding installations with standard inlay configuration and optional overlay installation using wide lateral brackets for barn door setups. It is built to support wood doors with a minimum thickness of 30 mm (1-3/16”) and a minimum frame height of 60 mm (2-3/8”). The system includes two DN150 CF carriers, two stoppers with retention devices, a GP-16 floor guide, two mounting plates, a segmenta key, and screws for secure assembly. For installations with three or more parallel panels, the use of the Floor Guide Track PL and the Floor Guide 17.5 MD is recommended to maintain constant floor connection. The DN150 CF is compatible with the U150 ST AL track, available in lengths of 2 m (6.5 ft), 3 m (9.85 ft), and 6 m (19.7 ft), offering versatile installation options. Tested under ANSI-BHMA standards, this carrier set is built to withstand demanding conditions while delivering precision and safety.
